Description
The all-new X|Flux 5 boasts a powerful 5hp motor and impressive 1823 CFM. Auto-cleaning of the HEPA filter is accomplished by double-paddles that sweep the filter every 3 minutes of system use in a clockwise and counterclockwise action. Remote and LED drum light are standard. The X|Flux 5 is a full-size stationary, single-stage dust collection unit with convenient 39 gallon drum on locking castors.
Special Order Item: Please allow 2-3 weeks delivery.
Specifications:
- Motor Specs: 5 HP
- Electrical Specs: 220V / 60Hz / 1PH / 3450 RPM
- Running AMP (8” inlet) 21.5 A at 220V
- Air Volume: 1823CFM (cubic feet per minute)
- Max. static pressure 12 Inches of water
- Fan size 14.5”
- Inlet: 8”
- Switch: High frequency remote control switch
- Collection capacity: 39 gallon Octagon drum x 1 set
- Packing Size: (L x W x H) 35.4” x 28.3” x 81.5” (90 x 72 x 207 cm)
- Machine weight 456 lbs. (207 kgs)
- Shipping weight 544 lbs. (247 kgs)
- Filter Media filtering area: 32.3 sq/ft (3m2)
- Cartridge Filter HEPA 19.7” x 19.7” (50 x 50cm) x 1pc ; (0.3-0.4 micron @ 99.7%)
